• Grinding process to ensure the surface are solid with good quality

Machine Spec
MODEL : CSG-2550 AH
Table size : 255x510 mm
Table travel : 280x560 mm
Max. table load : 300 kg
T- slot (No. x Width) : 1x14 mm
Longitudinal feed : 5～25 m/min
Cross feed (Manual feed) : 0.02 mm/div.
Grinding wheel : 200x25x32/31.75 mm
Wheel spindle speed : 2850 rpm
Wheelhead Vertical Movement (Feed of handwheel) : 0.01 mm/div.
Distance from table to spindle : 535 mm
Spindle motor power : 2.2 KW
Hydraulic motor power : 1.5 KW
Dust collector motor power : 550 W
Coolant motor power : 90 W
Cross feed motor power : 60 W
